Anti-Tearing Steel Cord Belt

Anti-Tearing Steel Cord Belt

Anti-Tearing Steel Cord Belt

Using high strength galvanized steel cord and special compound which is with excellent elasticity , not easy to corrode and giving a longer service life. Anti-tear steel cord conveyor belts are especially designed to transport hard and sharp materials to prevent foreign sharp materials entering the belt or prevent tearing the entire belt at longitudinal direction when the sharp materials are inserted into the belt.

Features and Benefits

  • Anti-tear steel cord conveyor belts are especially suitable for conditions where low elongation, cut and tear resistance are required.
  • One or two plies of anti-tear steel mesh are inserted between top cover and skim rubber, also between bottom cover and skim rubber.
  • Available cover rubber compounds including -50℃ to 300℃,fire resistant, oil and abrasion resistant
  • Excellent to deal with hard and sharp materials falling from heights
  • The belt has excellent anti-tearing performance, impact resistance, high-temperature firing resistance, high anti-tearing performance, and excellent trough ability and fatigue resistance; and gel can be completely permeated into the belt.

Technical Data

Specification Weight Pitch of
weft
Thickness Diameter Breaking
strength
Elongation
at break
Kg/m2 mm mm mm N %
KF-50 0.21 10 1.8 0.65 560 >2
KF-100 0.39 10 2.2 1 1050 >2
KF-125 0.63 8 2.4 1.18 1000 >5
KF-150 0.73 8 2.6 1.38 1360 >5
KF-200 0.92 6 2.6 1.38 1360 >5
KF-250 1.2 10 3.1 1.9 2530 >5
KF-300 1.32 8 3.1 1.9 2530 >5
KF-400 1.6 6 3.1 1.9 2530 >5
KF-500 2.22 5.6 3.3 2.02 2900 >5

 Type A -Abrasion Resistant

  • Cement Works: Quarries, open storage and reclamation, preblending.
  • Ports: Ship loading or unloading installaions .
  • Quarries: Primery and secondary conveyors.
  • Public Works: Boring, tunneling earthmoving.  Electricity Generating
  • Stations: Pre-blending, feed to hoppers, open storage and reclamation.
  • Sugar Mills: Handling of raw beets.
  • Pulp Mills: Handling of logs.
  • Coal Mines: Tipping, refilling, washing.
  • Steel Works: Iran ore hanling, open storage and reclamation, sinter plant, blast furnace feed,slag recovery.
