Breaker rubber conveyor belts

Breaker rubber conveyor belts

Vertical Bucket Elevator belting

Breaker rubber conveyor belts use more in Lift belting heights and heavy elevator buckets require an extremely strong transverse belt construction. This can be achieved with steel fabric reinforcement, a specially produced fabric comprising length cords and cross cords which are bound together to form a unified structure. This steel breaker conveyor belts is ideal for high temperature applications up to max. + 150˚C.

Cover Grade Tensile Strength Elongation Abrasion Loss
Min (Mpa) Min (%) Max (mm2)
DIN-W 18 450 90
DIN-Y 20 450 110
GRADE 1 17 450 120
GRADE 2 14 400 170
GRADE 1 HARK 18 450 90
MOR 12 1,400 300
SOR 15 300 200
FABRIC TYPE
NN Nylon / Nylon
EP Polyester / Nylon
SW Straight Wrap
CFW Crow Foot
BREAKER FABRIC Steel Mesh

steel breaker conveyor belts is one of the most efficient conveyor equipment to elevate a variety of bulk materials from light to heavy and from fine to large lumps, and it is widely used in the cement building materials, mining, steel, chemical industry, environmental protection, port wharf and so on. Bucket elevator system consists of a series of buckets attached to a belt or chain with pulleys or sprockets located at the top and bottom of the unit.

Working Principle:

High-speed Breaker rubber conveyor belts is the latest generation of vertical conveying equipment. A belt or chain is used as traction, and a series of buckets are fixed to the traction which will be driven to run by the head sprocket. The material will flow into the buckets automatically from the tail inlet, and along with the direction of the traction, the material will be transported to the head unit, then discharged from the head outlet.
