CHEMICAL RESISTANT CONVEYOR BELT
CHEMICAL RESISTANT CONVEYOR BELT is used for acidic or alkali materials conveying in chemical plant, pulp, cement, chemical fertilizer industry. Acid and alkali conveyor belt is a working environment suitable for the contact with acid-base, such as phosphate fertilizer manufacturing, sea salt and coating rubber used to mix and fill the inert materials with excellent acid and alkaline resistance.
Characters:
1.Prevent from acid or alkali ; corrosion to conveyor belt;
2.Good bonding property, no layers separation;
3.Cotton, polyester-cotton, nylon etc. materials are used for the belt core.
Rubber Cover Grade & Standard
Type | Rubber Cover Type | Tensile strength at break(N/mm2) | Elongation at break % | Abrasion mm3 |
Abrasion Resistant | RCB-AR-M | 24 | 450 | 120 |
RCB-AR-Y | 20 | 400 | 150 | |
RCB-AR-W | 18 | 400 | 90 | |
RCB-AR-N18 | 18 | 450 | 200 | |
RCB-AR-N | 17 | 400 | 200 | |
RCB-AR-A | 17 | 400 | 70 | |
RCB-AR-Z | 15 | 400 | 250 | |
RCB-AR-II | 14 | 350 | 280 | |
RCB-AR-L | 10 | 350 | 300 | |
Oil Resistant | RCB-FOR | 12 | 300 | 300 |
RCB-MOR | 15 | 450 | 250 | |
RCB-LOR | 17 | 450 | 200 | |
Heat Resistant | RCB-HR-T1-100oC | 17 | 400 | 250 |
RCB-HR-T2-125oC | 15 | 350 | 250 | |
RCB-HR-T3-150oC | 13 | 350 | 250 | |
RCB-HR-T4-180oC | 11 | 350 | 280 | |
RCB-HR-T5-300oC | 10 | 350 | 300 | |
FR/AR/AS Resistant | RCB-ARAS | 18 | 450 | 200 |
RCB-FRAS | 14 | 400 | 250 | |
RCB-FR | 12 | 350 | 300 | |
Cold Resistant | RCB-CR-T1– -30oC | 17 | 350 | 300 |
RCB-CR-T2– -50oC | 14 | 300 | 300 | |
Chemicl Resistant | RCB-ANTI-ACID | 14 | 400 | 250 |
RCB-ANTI-ALKALI | 14 | 400 | 250 |
Oil and Grease Resistant Conveyor Belt
MOR | OR | SOR | |
Tensile strength:min. | 12Mpa | 15MPa | 15MPa |
Abrasion Loss: max. | 250mm3 | 150mm3 | 150mm3 |
Belt Spec. Molded edge | |||
EP250/2-3+1 | |||
EP315/2-3+1 | |||
EP315/2-4+2 | |||
EP400/3-4+2 | |||
EP400/3-6+2 | |||
EP500/4-5+2 | |||
EP250/2-2+0-Must be cut edge | |||
EP400/3-2+0-Must be cut edge | |||
Please tell us your specification for quotation. |
Description:
CHEMICAL RESISTANT CONVEYOR BELT is suitable for the acid and alkali contact condition, eg phosphoric fertilizer abstracts salt from seawater. The covering layer rubber is the mixture of rubber and plastic and filled with acid resistant and alkali resistant inert materials, which is much better than LDR acid and alkali resistant conveyer belt. The framework material is EP canvas, which is more reliable and more alkali resistant and the cotton canvas core belt.
Acid and Alkali Resistant Belt Conveyor
The bucket elevator conveyor belt is a suitable choice for those seeking an abrasion resistant conveyor belt that offers long-term functionality through its design. The high strength and low elongation of the belt ensures vertical elevated conveying. To find out more about the product, contact us today by filling in our contact form.
