Mill Feeding belt
Hoppers for limestone/ clay/ iron ore serve the purpose of providing a buffer storage for mill feed and a convenient arrangement for feeding to weigh feeders for proportioning purpose. Hoppers used to be designed to hold the requirements of one shift. However, with raw mill capacities reaching 250-700 tph it is no longer practical to do so. Further with reclaimer belts of stacker reclaimer system running round the clock it is as well no longer necessary to do so. Thus hoppers may be designed to hold only 4 hours’ requirements. On the other hand, requirements of clay/silcastone, iron ore are very low that hoppers to hold 8 hours’ needs are too small. Therefore, for practical reasons hoppers for them would be designed to hold about 24 hours’ needs; but seldom more because of sluggish flow of these materials in hoppers. Whatever capacity and geometry you may be having in existing plant or planning to have in proposed plant, we need to be careful to check that the material segregation is minimum and that the disturbances by virtue of this phenomena are negligible.
Features:
Cover Compounds: Grade P, Fire-resistant, oil-resistant, Abrasion-resistant, Heat-resistant and Chemical-resistant.Steel cord conveyor belt
1. High tensile strength:Steel cord conveyor belt is suitable for large span,long distance transportation of materials
2. Small elongation in use:It need only a very short take-up stroke distance.
3. Small diameter of drive pulley:Steel cord conveyor belt body has a layer of longitudinally arranged steel cords as its skeleton,and thus is resistant to flex fatigue.Therefore,drive pulley of smaller diameter can be used to make the equipment smaller.
Standards offered: GB/T9770, DIN22131, EN ISO 15236, SANS1366 and AS1333.
