The Conveyor Belt with Steel Core for Board Feeder is a high-performance conveyor solution designed specifically for heavy-duty applications in industries such as mining, cement, and steel production. This belt is engineered to offer exceptional durability, strength, and reliability, making it ideal for transporting heavy materials over long distances with minimal wear and tear.

ST800 BELT WITH WIRE REINFORCED SBR
Steel wire cord-5mm
Laceration resistant mesh wire-Two layers
Thickness- 14 mm
Thickness of top cover – 5 mm
Thickness of bottom cover – 5 mm
Tensile strength- 800 N/mm
Conveying goods- coal
Lump size – 50-80 mm
Temperature of goods- aver. +25 C, maximum +60 C
Free lift height- 4 m
Travel speed – 2 m/sec
Conveyor capacity – 300 t/hour
Height of goods conveying – 33 m
Bulk weight of goods – 0.89 t/m3

2200mmW STEEL BELT /ST800

Key Features:

1. Steel Core Reinforcement: The belt is equipped with a high-tensile steel cord that provides superior strength and stability. This steel reinforcement ensures that the belt can handle high-tension loads and resist stretching, making it ideal for transporting heavy and abrasive materials.
2. Heat and Abrasion Resistance: The outer rubber cover is made from heat-resistant and abrasion-resistant materials, allowing the belt to operate in harsh environments where temperatures can reach up to 150°C, withstanding the demands of transporting hot and rough materials.
3. High Flexibility and Impact Resistance: Despite its robust construction, the belt retains flexibility, making it suitable for board feeder applications that require smooth and efficient material transfer. The belt can absorb impacts from large materials, reducing the risk of damage.
4. Long Service Life: With its reinforced steel core and high-quality rubber covering, the conveyor belt is designed to offer a longer service life, reducing downtime and maintenance costs.
