FR grade EN14973 C2 PVC Solid Woven Belt

PVC Flame Retardant Conveyor Belt:

Both top and bottom covers are PVC, thickness of each side can be up to 4mm, the belt has much
more advantages than non pressed PVC belt on impact resistance, water, with longer service life, higher fastener holding. Designed to meet the strictest underground safety standards, such as ISO 340 and EN 14973, our belts are ideal for use in coal mines and other high-risk environments. Our belts undergo rigorous flame tests, ensuring a total flame duration of less than 45 seconds for six samples.

PVG Flame Retardant Conveyor Belt:

Both top and bottom covers are PVG compound, much suitable to working at higher slope(better
no more than 20 degree).

Underground environments are prone to high concentrations of flammable gases (e.g., methane) and dust. Our flame-resistant belts significantly reduce the risk of fire and explosion.

Tensile strength: 500 ~ 2500N/mm.
Width: 500 ~ 2000mm.
Product models

Product model	Recommended minimum pulley diameter (mm)
800S	500
1000S	630
1250S	750
1400S	750
1600S	800
1800S	800
2000S	1000
2500S	1200

Physical properties

Type	Tensile strength (N/mm)		Elongation at break (%)		Tear strength (N)≥
Type	Longitudinal ≥	Transverse ≥	Longitudinal ≥	Transverse ≥	Tear strength (N)≥
800S	800	280	15	18	1180
1000S	1000	300			1180
1250S	1250	350			1540
1400S	1400	350			1540
1600S	1600	400
1800S	1800	400
2000S	2000	400
2500S	2500	400

Safety performance

Surface resistance average value	≤3×10 ≤3×10
Drum friction property	Drum temperature is not more than 325°C and shall not appear flame or on-fire burning.
Alcohol blast burner burning test	With cover: Average≤3S, Individual≤10S Without cover: Average≤5S, Individual≤15S

Applications;

FR grade EN14973 C2 PVC Solid Woven Belt for Coal mine underground transport,metallurgy and chemical industry,port,mining electric power industry,construction etc for the material transport
