K2 fire resistant conveyor belt
Polyester cotton conveyor belt is the up graded product of cotton conveyer
belt, and its tension resistant body is woven by polyester cotton fibers in
warp and cotton fibers in weft. Its comprehensive physical and mechanical
characteristics are obviously better than those of cotton conveyor belt,
especially the belt body is thinner and lighter, the belt had better shock
resistance and thus it has better performance and can reduce energy and
material consumption for users. It is the idea selection for medium,
short-distance and medium-load transpiration of materials
Cleat and sidewall techncial index list of anti static conveyor belt:
Base belt width | Sidewall height | Cleat height | Sidewall bottom width | Effective base belt width | Empty belt width |
300 | 40 | 35 | 25 | 180 | 35 |
60 | 55 | 50 | 120 | 40 | |
80 | 75 | ||||
400 | 60 | 55 | 50 | 180 | 60 |
80 | 75 | ||||
100 | 90 | ||||
500 | 80 | 75 | 50 | 250 | 75 |
100 | 90 | ||||
120 | 110 | ||||
650 | 100 | 90 | 50 | 350 | 100 |
120 | 110 | ||||
160 | 140 | 75 | 300 | ||
800 | 120 | 110 | 50 | 460 | 120 |
160 | 140 | 75 | 410 | ||
200 | 180 | ||||
1000 | 160 | 140 | 75 | 550 | 150 |
200 | 180 | ||||
240 | 220 | ||||
1200 | 160 | 140 | 75 | 690 | 180 |
200 | 180 | ||||
240 | 220 | ||||
300 | 260 | 100 | 640 | ||
1400 | 200 | 180 | 75 | 830 | 210 |
240 | 220 | ||||
300 | 260 | 100 | 780 | ||
400 | 360 |
