Portable elevator bucket belt with fasteners

Portable elevator bucket belt /10+8MM/1200MM/ST3150-EN14973 V CLASS C1/EN ISO 15236-3/ EN 14973-C1

14973 C1 =. This is standard FR (fire resistant) grade. Conveyor belts for use in underground, electrical and flammability safety requirements.

Features:

The Portable elevator bucket belt  (Transverse reinforcing cord belt) is made into a jointless endless conveyor belt (Portable elevator bucket belt  ) during the production process, which is characterized in that the belt core has no joints and does not affect the service life due to early damage of the joint. The surface of the tape is flat and the tension is uniform, so the tape runs smoothly and the elongation of use is small.

STEEL FABRIC REINFORCED ELEVATOR BELT: The TRANSVERSELY RIGID conveyor belts  refers to the Impact Resistant conveyor Belts that has made the conveyor belt into a jointless production belt. The strength of the core joint can reach 90% of the strength of the belt body, and the surface of the belt has no obvious joint. Defects, therefore, the tape transport balances and the use of elongation is small. The endless conveyor belt core is made of high quality cotton or cotton interwoven canvas, generally 2-6 layers or NN-200 nylon canvas (or polyester canvas) as a strong layer.

Endless belt length and limit deviation: endless belt length m limit deviation mm length less than 15 ± 50 length 15-20 ± 75 length greater than 20 belt length ± 0.5% The company can produce the appropriate length, width and thickness according to customer needs Ordinary, heat-resistant (≤120oC), cold-resistant (not less than -40oC), acid and alkali resistant, high temperature resistant (not higher than 150oC) and sanitary endless conveyor belt.

We occupied large focus on the quality of our collection and to ensure the same, we make use of excellent quality raw materials. These materials are obtained from our reliable and qualified vendors which are results of long term tenure. We are extremely focused for our work and have placed ourselves as one of the leading names in the industry.

Connected form:
The structure and processing method are substantially the same as those of the ordinary conveyor belt. The joint is not vulcanized into a whole by heating or pressing, so it is also called a jointless conveyor belt. There are three kinds of joint methods:

(1) direct vulcanization into a ring-shaped belt;

(2) retention of the head during vulcanization, and partial vulcanization of the joint according to the requirements of on-site heating and pressurization;

(3) bonding with an adhesive on site. Because it has no mechanical joints, it runs smoothly and is suitable for material transportation in the departments of mineral processing and fertilizer.
