PVC 450 Black Oil Resistant belt Cover x Cover
PVC 450 Black Oil Resistant belt Commonly used for elevator belting in the feed and grain industries. Features low stretch,
trouble-free operation, high bolt retention, resistant to grain oils, fi re, moisture, mildew, and rot.
Breaking strength can be measured to a certain break when required for Man Lift Elevators.
Temperature range: 20° F to 180° F. Thickness: 11/32”. Weight: .175 piw.
Minimum pulley diameter: 10” for conveyor / 14” for elevator service.
Recommended fasteners: #190 Solid Plate, #550 Bolt On, #R5 Rivet, #45 Alligator
PVC 250 Black Oil Resistant Static Conductive Cover x Cover
Commonly used for elevator belting in the feed and grain industries. Because of the low temperature, oil resistance, and static conductive qualities of this specifi cation, it provides excellent
service life in most agricultural environments. This belt won’t mildew or rot, is moisture resistant,
and has high bolt retention for bucket attachments.
Temperature range: 20° F to 180° F. Thickness: 5/16”. Weight: .150 piw.
Minimum pulley diameter: 8”. Recommended fasteners: #140 Solid Plate, #550 Bolt On,
#R5 Rivet, #35 Alligator.
PVC 150 Black Oil Resistant Cover x Cover
Proven belt for long wearing, high performance, problem free material handling applications.
Ideal for moving bulk materials, chemicals, fertilizers, and moderate sized product loads. Ideal
for a variety of roller bed and troughed applications. Characteristics include low stretch, high
strength, good fastener retention, with superior rip, tear, and gouge resistance.
Temperature range: 20° F to 180° F. Thickness: 13/64”. Weight: .100 piw.
Minimum pulley diameter: 4”. Recommended fasteners: #3 Hook, #187 Staple, #25 Alligator.
PVC 350 Black Oil Resistant Static Conductive Cover x Cover
Commonly used for elevator belting in the feed and grain industries. Features low stretch,
trouble-free operation, high bolt retention, resistant to grain oils, fi re, moisture, mildew, and rot.
Breaking strength can be measured when required for Man Lift Elevators.
Temperature range: 20° F to 180° F. Thickness: 5/16”. Weight: .158 piw.
Minimum pulley diameter: 8” for conveyors / 12” for elevators.
Recommended fasteners: #140 Solid Plate, #550 Bolt On, #R5 Rivet, #45 Alligator
