RMA-I & RMA-II Rubber Conveyor Belts  With the rapid development and integration of the world economy, conveyor belt products have played a very important role, especially in the field of bulk material transportation, mining and energy. Among all the technical standards of conveyor belts, the most commonly used ones are also the most important specification is the technical standard of the rubber cover.

All conveyor belts follow several internationally accepted rubber cover rating systems, most countries follow the German DIN22102 Grade standard, and of course there are regional grade standards, for example, American countries are accustomed to following the RMA grade standard, other countries also have their own overlay standards, such as China’s GB/T7984, Australia’s AS1332, Japan’s JISK6322, the United Kingdom’s BS-490 and South Africa’s SANS-1173, etc.

These standards are designed to provide end users with information on different applications refer to what grades are used in these ratings. These ratings specify different laboratory test standards, but do not provide any performance guarantees in specific applications.

In the selection of conveyor belts and international trade business, understand these standards and how to convert each other among these standards is very important, let’s take a look at the RMA-I & RMA-II Rubber Conveyor Belts standard:

RMA is the abbreviation of “Rubber Manufacturers Association”in United States, it has established two standard grades of rubber conveyor belt cover: RMA-I and RMA-II, the RMA-I (17Mpa) grade meets the higher requirements of rubber stretch and elongation, and usually shows higher cutting and scratch resistance than the RMA-II (14Mpa). It should be noted that grades do not necessarily indicate overall wear resistance. The International Organization for Standardization (ISO) also established a grading system under ISO 10247.

ANTI TEAR CONVEYOR BELT CONVEYOR 24” 1/4X1/16 375 PIW- RMA-1- 3 PLY ANTI TEAR (STEEL CAGE)

BELT CONVEYOR ABRASION RESIST.

CL (L GRADE 1S0 10247-Y GRADE DIN22102-RMA II GRADE)- STANDARD ABRASION RESISTANT COMPOUND MOULDED EDGES

Scope of application: applicable to industries, mining, coal mines, cement, steel, power plants, ports, agriculture, construction and other fields.

This standard includes:

Category H (Severe Cut and Gouge Service, Category)

Category D (Severe Abrasion Service)

Category L (Moderate Service).

Among them, category H is roughly comparable to RMA Grade I; categories D and L approximate RMA Grade II belting.

ARPM (Association for Rubber Products Manufacturers), a successor of RMA. Published their conveyor belt handbook in 2011, determining grade 1 with tensile strength of 17 MPa, elongation at break of 400 % and volume loss of 125 mm³, and grade 1 with tensile strength of 14 MPa, elongation at break of 400 % and volume loss of 175 mm³, This means that the standards established by ARPM have higher requirements for abrasion rate.

Performance characteristics and application of RMA-I rubber cover

• 1. RMA Grade I rubber compound
• 2. Superior resistance to cutting, gouging and tearing from the impact of large materials
• 3. High abrasion resistance and excellent low temperature flexibility
• 4. Recommended for service with all kinds of hard, sharp ores, quartz, trap rock, riprap, granite, glass cullet, scrap metal, ballast, etc.



Performance characteristics and application of RMA-II rubber cover

• 1. RMA Grade II rubber compound
• 2. Durable and long-lasting in abrasive applications
• 3. Resistant to cuts and gouges, flexible at lower temperatures
• 4. Ideal for conveying sand and gravel, lime stone, crushed rock, slag, coke, coal, cement rock, phosphate rock and most material weighing between 50 and 120 Ibs. per cubic foot



Main Technical Parameter for RMA-I and RMA-II:

Standards	Cover Rubber			Adhesion
	Tensile Strength	Elongation at break	Abrasion	Cover to Ply	Cover to	Ply to Ply
RMA	Mpa	%	mm3	N/mm	N/mm	N/mm
RMA-I	17	400	200	3	4.4	4
RMA-II	14	400	250	3	4.4	4
ARPM-1	17	400	125	3	4.4	4
ARPM-2	14	400	175	3	4.4	4

There are also some conveyor belts used in special environments, such as the transportation of high-temperature materials, chemically corrosive materials, underground mines or oily materials or chemicals. Such environments have special requirements on the chemical properties of rubber, such as heat resistance, oil resistance and flame retardancy, etc., so it is best to understand the operating conditions first, and then consult a reputable supplier before choosing the conveyor belt category.

Technical Specification for Other Rubber Grade:

RMA Norm	Characterization	Tensile Strength in Mpa (min)	Elongation at break %(min)	Abrasion in mm3(max)	Hardness in SHA	Basic Material
/	Extreme abrasion resistance,super ior resistance to cutting & tearing	24	450	120	60±5	NR/SBR
RMAI	High abrasion resistance,superior resistance to cutting & tearing	17	450	200	60±5	NR/SBR
RMA II	Resistant to cuts and gouges,flexible at lower temperatures	14	400	250	60±5	NR/SBR
MHSA	Flame Retardant	15	350	200	60±5	CR
/	Oil Resistant	15	400	200	60±5	NBR
/	Chemical Resistant	15	400	250	60±5	CR/IIR
/	Anti-Static	15	400	200	60±5	NR/SBR
/	Heat Resistant+100℃~+175C	15	400	200	60±5	SBR/EPDM

Troughability-	minimum belt width (imperial)
Idlers	PIW 220/2	PIW 250/2	PIW 300/2	PIW 400/2	PIW 330/3	PIW 375/3	PIW 500/3	PIW 600/3	PIW 750/3
20 degree idlers	16	16	18	18	24	24	24	30	36
35 degree idlers	18	18	24	24	24	24	24	30	36
45 degree idlers	24	24	30	30	30	30	30	36	42
