Corrugated sidewall conveyor belt is also called sidewall rubber conveyor belt. The sidewall belt conveyor design is required to have certain tensile strength and abrasion resistance. For the sidewall conveyor belt with empty edge, in order to meet the requirements of the angle direction, the longitudinal direction of the belt should be flexible and the transverse direction should be rigid. The corrugated sidewall belt conveyor retaining conveyor belt produced by our company adopts the transverse rigid base belt of special structure to solve the belt collapse phenomenon of large-size conveyor belt in the return process.

Corrugated sidewall belt Base belt Construction:
The side wall conveyor belt base is composed of four parts: upper covering glue, lower covering glue, belt core and transverse rigid layer. The thickness of upper covering glue is generally 3-6mm;

Sidewall conveyor belt, also known as corrugated sidewall conveyor belt , is a design of adding two wavy skirt edges on the basis of flat conveyor belt, This design prevents the conveyor belt from sliding from both sides when transporting goods. What are the advantages of Monster’s sidewall conveyor belt in processing technology? Let’s have a look.

1. The sidewall height of the sidewall conveyor belt can be customized according to the requirements of users, meeting the actual needs of customers.
2. The sidewall rubber conveyor belt is generally made of PVC and PC, with high strength and wear-resistant base belt, high transverse stiffness and longitudinal flexibility.
3. The sidewall and base belt are all seamless joints, which can transport powdery, granular, small block, paste and liquid materials that are easy to fall.
4. The conveying angle of materials can be increased (30 ~ 90 degrees).
5. Smooth transition from horizontal to inclined or vertical.
6. The corrugated sidewall belt can be equipped with baffle to avoid the problem of base bellt deviation.
The above is an introduction to the process characteristics of the skirt conveyor belt. Monster belting supports the customization of products. If you need non-standard conveyor belt products, we also provides you with technical support . Welcome to inquire

1. Mechanical joint
   Generally, it refers to the use of belt buckle joints (such as needle, butterfly and wolf tooth buckle). This kind of joint method is convenient and fast, which has a certain impact on the service life of conveyor belt products. In PVC and PVG whole core flame retardant and antistatic conveyor belt joints, this joint method is generally used for products below grade 8 belt.
   The disadvantage is that it is not easy to clean, easy to breed bacteria, long service time is easy to cause the conveyor belt joint to tear slowly, and the service life will be short. This kind of joint can be selected when the machine is inconvenient to disassemble.
2. Cold bonded joint
   That is, cold adhesive is used for joint. This joint method is more efficient and economical than mechanical joint, and should have better joint effect. However, in practice, it is not very stable because it is difficult to master the process conditions and the quality of adhesive has a great impact on the joint.
3. Hot vulcanized joint
   The hot vulcanization joint method adopts the layered bonding belt joint, and the joint bonding is realized by heating, pressurization and other methods. This method is applicable to large-scale conveying equipment and is the most ideal joint method at present. It can make the conveyor belt joint completely sealed, free from moisture, long service life and stable operation of the belt. The PVC conveyor belt produced by Jinan Monster beltingbelt is mostly hot vulcanization joint method.
