Conveyor belt Usage
conveyor belt Usage Oil resistant conveyor belt, antiskid belt, corrugated sidewall conveyor belt, heat transfer anti acid cold conveyor belt, water proof belt, moisture-proof conveyor belt conveyor belt, heat resistant belt, Cold resistant conveyor belt conveyor with high temperature resistance, acid and alkali belt, fire resistant belt.
Conveyor belt Usage – Grade of heat resistance belt:
1. Heat resistant conveyor belt: TI type is not more than 100 degrees, T2 type is not more than 125 degrees, T3 type is not more than 150 degrees.
2, high temperature resistant belt: the temperature resistance is not more than 200 degrees
Heat resistant conveyor belt (metal mesh core conveyer belt): temperature resistance 200-500 degrees
Conveyor belt Usage – Tensile Strength standard of conveyor belt:
The general purpose belt is according to the GB7984-2001 standard.
general purpose belt: cover tensile strength of not less than 15Mpa, tensile elongation of not less than 350%, the wear volume is less than or equal to 200mm3; belt strength between the layers is not less than the average value of the longitudinal 3.2N/mm cloth layers; cover rubber and cloth layers is not less than 2.1N/mm; the thickness of longitudinal elongation of not less than 10%; the thickness of longitudinal reference force elongation is not greater than 1.5%.
Nylon (NN), polyester (EP) covering layer of belt, the tensile strength of not less than 15Mpa, tensile elongation of not less than 350%, and the belt strength between the layers is not less than the average value of the longitudinal 4.5N/mm layers of cloth, cover rubber and cloth layer is not less than 3.2N/mm, the thickness of longitudinal elongation of not less than 10%, full thickness the longitudinal reference force elongation of not more than 4%, plastic cover with rubber blend, the tensile strength coefficient of skeleton GB level, can lap the endless.
Conveyor belt Usage -General-purpose belt
General belt, special for fire resistant, antistatic, heat-resistant, chemical resistance and oil, low temperature, food conveyor belt.
According to the form of expression: plane shape, groove shape, deep groove shape, wave shape edge type, entrainment type, baffle type, round tube type, flat tube type, embossing shape.
According to the type of core: fabric like cotton canvas, synthetic fiber (viscose, polyamide, polyester and cotton fiber blended or prepared)
Steel type: wire rope, steel fiber, steel belt, steel cord fabric
According to strength: low strength (less than 300 KN /m), medium strength (300-1250 KN /m), high strength (greater than 1250 KN /m)
