Super width EP conveyor belt with bare back

Super width EP conveyor belt with bare back

Product Description

When the belt is wider than 1800mm, we call it super width belt. Monster has 2400mm and  6500mm wide vulcanizing machines, which can make belts from 1800-5500mm. Thickness can be from 12-42mm.

 The surface is smooth due to good quality of equipment and good production process.  Customers can customize different belts based on different special requirements.

The belt maximum width is 6.8 meters with cut edge. And the belt carcass is 2-4plies with oil resistant. The thickness can be 4 mm lower.

The Super width EP conveyor belt with bare back outer surface of the top or bottom of the fabric of a bareback belt has neither an elastomeric compound cover nor is it impregnated with an elastomeric compound. A Super width EP conveyor belt with bare back is with back fabric surface provides a low coefficient of friction. A slider bed package conveyor with the bareback surface down against the slider bed or the bareback surface up in connection with a diverter bar are examples of bareback surface applications.

Cover Properties of the belts:

Cover Grade Tensile Strength ≥ Elongation ≥ Abrasion ≥ Change Rate of tensile strength and
elongation after aging  %
Mpa kgf/cm2
Heavy(H) 18 180 400 0.7 -25 to 25
Medium(M) 14 140 350 0.8 -25 to 25
Light(L) 10 100 300 1 -30 to 30

Adhesion and elongation of the belt:

Belt Carcass Adhesive Strength Elongation
Between plies N/MM Between rubber and carcass Longitudinal elongation at break% ≥ Longitudinal elongation at load% ≤
Rubber thickness≤1.5mm Rubber Thickness>1.5mm
Cotton Canvas ≥4.05 ≥3.15 ≥3.50 10 2
Monster belting | Super width EP conveyor belt with bare back

Delivery time: 30-60 days
  Quality control:  Quality is controlled by technical and inspection teams under different standards.
  Package: packing according to different requirements
  Rubber cover features: different formulas will be applied to make different rubber covers to fit special working conditions.
